PTZ Setup
- If you press button 1 + set for 2 to 3 seconds, you can enter into the PTZ setup menu.
- Input : the password (factory default 0000)
- Address: input the camera address (1-255)
- Model : (find the camera which user want to control by the joystick
- Baudrate: (set the baudrate of the camera)
- Parity: none(set the parity none/even/odd)
- Prop: on (set the camera speed)
- Save : save (the settings)
- Exit : exit (PTZ setup menu)
Main Setup
- If you press 2+set for 2-3 seconds, you can enter into the main setup.
- Main setup: enter the password(factory set:0000)
- Version: show the software version and date.
- Date: shows the current date.
- Title Set: ACB enter the title.
- Control ID: ID number can be changed.
- DVR SPD: 24KBPS-57.6KBPS
- Backlight: auto
- Sleep: setting to save power in the standby mode (off by default)
- Buzzer: (on by default)
- Terminate: (on by default)
- Joystick SPD: select the joystick speed from 50ms to 300ms.
- Mouse SPD: mouse speed setting when operated with DVR.
- Password: change the password if needed.
- Factory Setup: you hit yes if you want to go back to factory settings.
- Save/exit: no or yes after you make changes.
